<style name="Theme.Light">
	<item name="isLightTheme">true</item>
	<item name="windowBackground">@drawable/screen_background_selector_light</item>
...
</style>

// 方式1：在应用的主题中添加如下的一行属性
<item name="android:windowBackground">@android:color/transparent</item>
<!-- 或者 -->
<item name="android:windowBackground">@null</item>

// 方式2：在 BaseActivity 的 onCreate() 方法中使用下面的代码移除
getWindow().setBackgroundDrawable(null);
<!-- 或者 -->
getWindow().setBackgroundDrawableResource(android.R.color.transparent);

	@Override
    protected boolean drawChild(Canvas canvas, View child, long drawingTime) {
        final int height = getHeight();
        final boolean drawingContent = isContentView(child);
        int clipLeft = 0, clipRight = getWidth();

        //保存当前的canvas绘图状态到保存栈中，方便在后续使用canvas.restoreToCount(restoreCount)恢复回来
        final int restoreCount = canvas.save();
        if (drawingContent) {
            final int childCount = getChildCount();
            //遍历DrawerLayout的childView,拿到抽屉布局
            for (int i = 0; i < childCount; i++) {
                final View v = getChildAt(i);
                //如果不是抽屉布局就跳过
                if (v == child || v.getVisibility() != VISIBLE
                        || !hasOpaqueBackground(v) || !isDrawerView(v)
                        || v.getHeight() < height) {
                    continue;
                }

                //如果是左抽屉布局
                if (checkDrawerViewAbsoluteGravity(v, Gravity.LEFT)) {
                    final int vright = v.getRight(); //拿到他的右边的距离
                    if (vright > clipLeft) clipLeft = vright; //如果他右边的距离把之前裁剪的左边距覆盖了，就更新剩余部分左距离
                } else {
                    //如果是右抽屉布局
                    final int vleft = v.getLeft(); //拿到他左边的距离
                    if (vleft < clipRight) clipRight = vleft; //更新剩余部分的右边距
                }
            }
            //四个参数分别代表左边，顶部，右边，底部的距离
            canvas.clipRect(clipLeft, 0, clipRight, getHeight()); //裁剪出原布局的剩余显示范围，避免过度绘制
        }
        ...
    }

SoftReference<Object> softRef = new SoftReference<>(new Object());

WeakReference<Object> weakRef = new WeakReference<>(new Object());

fun concatenateStrings(strings: List<String>): String {
    var result = ""
    for (str in strings) {
        result += str // 每次拼接都会创建一个新的 String 对象
    }
    return result
}

fun concatenateStrings(strings: List<String>): String {
    val builder = StringBuilder()
    for (str in strings) {
        builder.append(str) // 使用 StringBuilder 减少对象分配
    }
    return builder.toString()
}

class ImagePool {
    private val pool = SparseArray<Bitmap>()

    // 从池中借用图片
    fun borrowImage(key: Int): Bitmap? {
        return pool.get(key)
    }

    // 归还图片到池中
    fun returnImage(key: Int, bitmap: Bitmap) {
        pool.put(key, bitmap)
    }
}

class MainActivity : AppCompatActivity() {
    // 静态Handler，避免隐式持有Activity
    private val handler = MyHandler(this)

    private class MyHandler(activity: MainActivity) : Handler(Looper.getMainLooper()) {
        private val activityRef = WeakReference(activity) // 弱引用

        override fun handleMessage(msg: Message) {
            val activity = activityRef.get()
            activity?.let {
                // 仅当Activity存活时处理消息
            }
        }
    }

    override fun onDestroy() {
        super.onDestroy()
        handler.removeCallbacksAndMessages(null) // 移除所有消息
    }
}

debugImplementation 'com.squareup.leakcanary:leakcanary-android:2.9.1'

class MainActivity2 : AppCompatActivity() {
    @SuppressLint("MissingInflatedId")
    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main2)
        MyThread().start()
        findViewById<Button>(R.id.btn_click2).setOnClickListener {
//            Thread.sleep(30000)
            finish()
        }
    }

    inner class MyThread : Thread() {
        override fun run() {
            sleep(60*1000)
        }
    }

}

fun main() {
    var obj: Any? = Object()
    val referenceQueue = ReferenceQueue<Any?>()
    val weakReference = WeakReference<Any?>(obj,referenceQueue) //将obj与弱引用关联，再将弱引用与引用队列关联

    var ref = referenceQueue.poll() //此时未进行回收
    println("before:$ref") //输出引用队列

    obj = null //将他置空，与Object()的引用断开
    System.gc() //进行垃圾回收
    Thread.sleep(2000)

    ref = referenceQueue.poll() //此时被回收后，obj会添加到引用队列中
    println("after:$ref") //输出引用队列
}

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.squareup.leakcanary.objectwatcher" >

    <uses-sdk android:minSdkVersion="14" />

    <application>
        <provider
            android:name="leakcanary.internal.MainProcessAppWatcherInstaller"
            android:authorities="${applicationId}.leakcanary-installer"
            android:enabled="@bool/leak_canary_watcher_auto_install"
            android:exported="false" />
    </application>

</manifest>

internal class MainProcessAppWatcherInstaller : ContentProvider() {

  override fun onCreate(): Boolean {
    val application = context!!.applicationContext as Application
    AppWatcher.manualInstall(application) //在onCreate()中初始化AppWatcher
    return true
  }

  ...
}

  @JvmOverloads
  fun manualInstall(
    application: Application,
    retainedDelayMillis: Long = TimeUnit.SECONDS.toMillis(5), //对检测对象延迟5秒检测
    watchersToInstall: List<InstallableWatcher> = appDefaultWatchers(application)
  ) {
    checkMainThread()
    if (isInstalled) {
      throw IllegalStateException(
        "AppWatcher already installed, see exception cause for prior install call", installCause
      )
    }
    check(retainedDelayMillis >= 0) {
      "retainedDelayMillis $retainedDelayMillis must be at least 0 ms"
    }
    this.retainedDelayMillis = retainedDelayMillis
    if (application.isDebuggableBuild) {
      LogcatSharkLog.install() //日志的初始化
    }
    // 核心组件
    LeakCanaryDelegate.loadLeakCanary(application)

    //对每一个检测器进行初始化
    watchersToInstall.forEach {
      it.install()
    }
    // Only install after we're fully done with init.
    installCause = RuntimeException("manualInstall() first called here")
  }

 fun appDefaultWatchers(
    application: Application,
    reachabilityWatcher: ReachabilityWatcher = objectWatcher
  ): List<InstallableWatcher> {
    return listOf(
      ActivityWatcher(application, reachabilityWatcher), //对Activity的检测器
      FragmentAndViewModelWatcher(application, reachabilityWatcher), //对Fragment和Viewmodel的检测器
      RootViewWatcher(reachabilityWatcher), //对RootView的检测器
      ServiceWatcher(reachabilityWatcher) //对Service的检测器
    )
  }

class ActivityWatcher(
  private val application: Application,
  private val reachabilityWatcher: ReachabilityWatcher
) : InstallableWatcher {

  private val lifecycleCallbacks =
    object : Application.ActivityLifecycleCallbacks by noOpDelegate() {
      override fun onActivityDestroyed(activity: Activity) {
        reachabilityWatcher.expectWeaklyReachable(
          activity, "${activity::class.java.name} received Activity#onDestroy() callback"
        )
      }
    }

  override fun install() {
    application.registerActivityLifecycleCallbacks(lifecycleCallbacks) //注册Activity生命周期的监听
  }

  override fun uninstall() {
    application.unregisterActivityLifecycleCallbacks(lifecycleCallbacks)
  }
}

  val objectWatcher = ObjectWatcher(
    clock = { SystemClock.uptimeMillis() },
    checkRetainedExecutor = {
      // ObjectWatcher被AppWatcher用来检测保留的对象。仅当isInstalled为true时设置。
      check(isInstalled) {
        "AppWatcher not installed"
      }
      mainHandler.postDelayed(it, retainedDelayMillis)
    },
    isEnabled = { true }
  )

  @Synchronized override fun expectWeaklyReachable(
    watchedObject: Any,
    description: String
  ) {
    if (!isEnabled()) {
      return
    }
    removeWeaklyReachableObjects() //清空观察区里面被回收的对象
    //生成UUID Key，便于从列表中取出相应的引用
    val key = UUID.randomUUID()
      .toString()
    val watchUptimeMillis = clock.uptimeMillis()
    //这里的KeyedWeakReference是弱引用的一个包装类，将观察对象进行弱引用，并且与引用队列关联
    val reference =
      KeyedWeakReference(watchedObject, key, description, watchUptimeMillis, queue)
    SharkLog.d {
      "Watching " +
        (if (watchedObject is Class<*>) watchedObject.toString() else "instance of ${watchedObject.javaClass.name}") +
        (if (description.isNotEmpty()) " ($description)" else "") +
        " with key $key"
    }

    //在观察列表中登记
    watchedObjects[key] = reference

    //开启子线程检测对象是否关联
    checkRetainedExecutor.execute {
      moveToRetained(key)
    }
  }

  private fun removeWeaklyReachableObjects() {
    // WeakReferences are enqueued as soon as the object to which they point to becomes weakly
    // reachable. This is before finalization or garbage collection has actually happened.
    var ref: KeyedWeakReference?
    do {
      ref = queue.poll() as KeyedWeakReference?
      if (ref != null) {
        watchedObjects.remove(ref.key)
      }
    } while (ref != null)
  }

  @Synchronized private fun moveToRetained(key: String) {
    removeWeaklyReachableObjects()
    val retainedRef = watchedObjects[key] //通过唯一的UUID取出观察对象
    if (retainedRef != null) {
      retainedRef.retainedUptimeMillis = clock.uptimeMillis() //这个是关联对象被认为保留的时间
      // 责任链模式，会在后面的核心组件里面设置
      onObjectRetainedListeners.forEach { it.onObjectRetained() }
    }
  }

class FragmentAndViewModelWatcher(
  private val application: Application,
  private val reachabilityWatcher: ReachabilityWatcher
) : InstallableWatcher {

  private val fragmentDestroyWatchers: List<(Activity) -> Unit> = run {
    val fragmentDestroyWatchers = mutableListOf<(Activity) -> Unit>()

    if (SDK_INT >= O) {
      fragmentDestroyWatchers.add(
        AndroidOFragmentDestroyWatcher(reachabilityWatcher)
      )
    }

    // AndroidX版本
    getWatcherIfAvailable(
      ANDROIDX_FRAGMENT_CLASS_NAME,
      ANDROIDX_FRAGMENT_DESTROY_WATCHER_CLASS_NAME,
      reachabilityWatcher
    )?.let {
      fragmentDestroyWatchers.add(it)
    }

    // Android老版本
    getWatcherIfAvailable(
      ANDROID_SUPPORT_FRAGMENT_CLASS_NAME,
      ANDROID_SUPPORT_FRAGMENT_DESTROY_WATCHER_CLASS_NAME,
      reachabilityWatcher
    )?.let {
      fragmentDestroyWatchers.add(it)
    }
    fragmentDestroyWatchers
  }

  private val lifecycleCallbacks =
    object : Application.ActivityLifecycleCallbacks by noOpDelegate() {
      override fun onActivityCreated(
        activity: Activity,
        savedInstanceState: Bundle?
      ) {
        // 对不同版本的FragmentDestroyWatcher进行监听注册
        for (watcher in fragmentDestroyWatchers) {
          watcher(activity)
        }
      }
    }

  override fun install() {
    application.registerActivityLifecycleCallbacks(lifecycleCallbacks)
  }

  override fun uninstall() {
    application.unregisterActivityLifecycleCallbacks(lifecycleCallbacks)
  }
  ...
}

  companion object {
    private const val ANDROIDX_FRAGMENT_CLASS_NAME = "androidx.fragment.app.Fragment"
    private const val ANDROIDX_FRAGMENT_DESTROY_WATCHER_CLASS_NAME =
      "leakcanary.internal.AndroidXFragmentDestroyWatcher"
	...
  }

internal class AndroidXFragmentDestroyWatcher(
  private val reachabilityWatcher: ReachabilityWatcher
) : (Activity) -> Unit {

  private val fragmentLifecycleCallbacks = object : FragmentManager.FragmentLifecycleCallbacks() {

    override fun onFragmentCreated(
      fm: FragmentManager,
      fragment: Fragment,
      savedInstanceState: Bundle?
    ) {
      // 对ViewModel的一些监听
      ViewModelClearedWatcher.install(fragment, reachabilityWatcher)
    }

    override fun onFragmentViewDestroyed(
      fm: FragmentManager,
      fragment: Fragment
    ) {
      val view = fragment.view
      if (view != null) {
        // 对View泄漏的回调
        reachabilityWatcher.expectWeaklyReachable(
          view, "${fragment::class.java.name} received Fragment#onDestroyView() callback " +
          "(references to its views should be cleared to prevent leaks)"
        )
      }
    }

    override fun onFragmentDestroyed(
      fm: FragmentManager,
      fragment: Fragment
    ) {
      // 这里和activityWatcher差不多，不多解释了
      reachabilityWatcher.expectWeaklyReachable(
        fragment, "${fragment::class.java.name} received Fragment#onDestroy() callback"
      )
    }
  }

  override fun invoke(activity: Activity) {
    if (activity is FragmentActivity) {
      val supportFragmentManager = activity.supportFragmentManager
      // 通过FragmentManager监听Fragment生命周期
      supportFragmentManager.registerFragmentLifecycleCallbacks(fragmentLifecycleCallbacks, true)
      // 初始化ViewModel
      ViewModelClearedWatcher.install(activity, reachabilityWatcher)
    }
  }
}

internal class ViewModelClearedWatcher(
  storeOwner: ViewModelStoreOwner,
  private val reachabilityWatcher: ReachabilityWatcher
) : ViewModel() {

  // We could call ViewModelStore#keys with a package spy in androidx.lifecycle instead,
  // however that was added in 2.1.0 and we support AndroidX first stable release. viewmodel-2.0.0
  // does not have ViewModelStore#keys. All versions currently have the mMap field.
  private val viewModelMap: Map<String, ViewModel>? = try {
    // 通过反射获取ViewModelStore
    val mMapField = ViewModelStore::class.java.getDeclaredField("mMap")
    mMapField.isAccessible = true
    @Suppress("UNCHECKED_CAST")
    mMapField[storeOwner.viewModelStore] as Map<String, ViewModel>
  } catch (ignored: Exception) {
    null
  }

  override fun onCleared() {
    // 当ViewModel销毁时，意味着viewModelStore里的其他ViewModel也会被销毁
    viewModelMap?.values?.forEach { viewModel ->
      reachabilityWatcher.expectWeaklyReachable(
        viewModel, "${viewModel::class.java.name} received ViewModel#onCleared() callback"
      )
    }
  }

  companion object {
    fun install(
      storeOwner: ViewModelStoreOwner,
      reachabilityWatcher: ReachabilityWatcher
    ) {
      // 将自己插入viewModelStore来监控通一宿主的viewmodel
      val provider = ViewModelProvider(storeOwner, object : Factory {
        @Suppress("UNCHECKED_CAST")
        override fun <T : ViewModel?> create(modelClass: Class<T>): T =
          ViewModelClearedWatcher(storeOwner, reachabilityWatcher) as T
      })
      provider.get(ViewModelClearedWatcher::class.java)
    }
  }
}

class RootViewWatcher(
  private val reachabilityWatcher: ReachabilityWatcher
) : InstallableWatcher {

  private val listener = OnRootViewAddedListener { rootView ->
    val trackDetached = when(rootView.windowType) {
      PHONE_WINDOW -> {
        // 拿到当前窗口的回调对象
        when (rootView.phoneWindow?.callback?.wrappedCallback) {
          // Activities are already tracked by ActivityWatcher
          is Activity -> false
          is Dialog -> {
            // Use app context resources to avoid NotFoundException
            // https://github.com/square/leakcanary/issues/2137
            val resources = rootView.context.applicationContext.resources
            resources.getBoolean(R.bool.leak_canary_watcher_watch_dismissed_dialogs)
          }
          // Probably a DreamService
          else -> true
        }
      }
      // Android widgets keep detached popup window instances around.
      POPUP_WINDOW -> false
      TOOLTIP, TOAST, UNKNOWN -> true
    }
    // 最后返回的是是否需要追踪这个窗口
    if (trackDetached) {
      rootView.addOnAttachStateChangeListener(object : OnAttachStateChangeListener {

        val watchDetachedView = Runnable {
          reachabilityWatcher.expectWeaklyReachable(
            rootView, "${rootView::class.java.name} received View#onDetachedFromWindow() callback"
          )
        }

        override fun onViewAttachedToWindow(v: View) {
          mainHandler.removeCallbacks(watchDetachedView)
        }

        override fun onViewDetachedFromWindow(v: View) {
          mainHandler.post(watchDetachedView)
        }
      })
    }
  }

  override fun install() {
    Curtains.onRootViewsChangedListeners += listener
  }

  override fun uninstall() {
    Curtains.onRootViewsChangedListeners -= listener
  }
}

class ServiceWatcher(private val reachabilityWatcher: ReachabilityWatcher) : InstallableWatcher {
  ...
  override fun install() {
    checkMainThread()
    check(uninstallActivityThreadHandlerCallback == null) {
      "ServiceWatcher already installed"
    }
    check(uninstallActivityManager == null) {
      "ServiceWatcher already installed"
    }
    try {
      swapActivityThreadHandlerCallback { mCallback ->
        uninstallActivityThreadHandlerCallback = {
          swapActivityThreadHandlerCallback {
            mCallback
          }
        }
        Handler.Callback { msg ->
          // https://github.com/square/leakcanary/issues/2114
          // On some Motorola devices (Moto E5 and G6), the msg.obj returns an ActivityClientRecord
          // instead of an IBinder. This crashes on a ClassCastException. Adding a type check
          // here to prevent the crash.
          if (msg.obj !is IBinder) {
            return@Callback false
          }

          if (msg.what == STOP_SERVICE) {
            val key = msg.obj as IBinder
            activityThreadServices[key]?.let {
              onServicePreDestroy(key, it)
            }
          }
          mCallback?.handleMessage(msg) ?: false
        }
      }
      swapActivityManager { activityManagerInterface, activityManagerInstance ->
        uninstallActivityManager = {
          swapActivityManager { _, _ ->
            activityManagerInstance
          }
        }
        Proxy.newProxyInstance(
          activityManagerInterface.classLoader, arrayOf(activityManagerInterface)
        ) { _, method, args ->
          if (METHOD_SERVICE_DONE_EXECUTING == method.name) {
            val token = args!![0] as IBinder
            if (servicesToBeDestroyed.containsKey(token)) {
              onServiceDestroyed(token)
            }
          }
          try {
            if (args == null) {
              method.invoke(activityManagerInstance)
            } else {
              method.invoke(activityManagerInstance, *args)
            }
          } catch (invocationException: InvocationTargetException) {
            throw invocationException.targetException
          }
        }
      }
    } catch (ignored: Throwable) {
      SharkLog.d(ignored) { "Could not watch destroyed services" }
    }
  }
  ...
  private fun onServiceDestroyed(token: IBinder) {
    servicesToBeDestroyed.remove(token)?.also { serviceWeakReference ->
      serviceWeakReference.get()?.let { service ->
        reachabilityWatcher.expectWeaklyReachable(
          service, "${service::class.java.name} received Service#onDestroy() callback"
        )
      }
    }
  }
  ...
}

  @JvmOverloads
  fun manualInstall(
    application: Application,
    retainedDelayMillis: Long = TimeUnit.SECONDS.toMillis(5),
    watchersToInstall: List<InstallableWatcher> = appDefaultWatchers(application)
  ) {
    ...
    // Requires AppWatcher.objectWatcher to be set
    LeakCanaryDelegate.loadLeakCanary(application) //这里就是核心组件，用于检测泄漏和对堆转储的分析

    watchersToInstall.forEach {
      it.install()
    }
    // Only install after we're fully done with init.
    installCause = RuntimeException("manualInstall() first called here")
  }

internal object LeakCanaryDelegate {

  @Suppress("UNCHECKED_CAST")
  val loadLeakCanary by lazy {
    try {
      // 通过反射实例化了InternalLeakCanary，并且调用了invoke()方法
      val leakCanaryListener = Class.forName("leakcanary.internal.InternalLeakCanary")
      leakCanaryListener.getDeclaredField("INSTANCE")
        .get(null) as (Application) -> Unit
    } catch (ignored: Throwable) {
      NoLeakCanary
    }
  }

  object NoLeakCanary : (Application) -> Unit, OnObjectRetainedListener {
    override fun invoke(application: Application) {
    }

    override fun onObjectRetained() {
    }
  }
}

  override fun invoke(application: Application) {
    _application = application // 传入application

    checkRunningInDebuggableBuild()

    // 这里就是之前在ActivityWatcher中设置的onObjectRetainedListener()
    AppWatcher.objectWatcher.addOnObjectRetainedListener(this)

    // 创建GC触发器，这样GC更容易触发垃圾回收
    val gcTrigger = GcTrigger.Default

    val configProvider = { LeakCanary.config }

    val handlerThread = HandlerThread(LEAK_CANARY_THREAD_NAME)
    handlerThread.start()
    val backgroundHandler = Handler(handlerThread.looper)

    // 创建分析堆转储的启动器
    heapDumpTrigger = HeapDumpTrigger(
      application, backgroundHandler, AppWatcher.objectWatcher, gcTrigger,
      configProvider
    )
    application.registerVisibilityListener { applicationVisible ->
      this.applicationVisible = applicationVisible
      heapDumpTrigger.onApplicationVisibilityChanged(applicationVisible)
    }
    registerResumedActivityListener(application)
    addDynamicShortcut(application) // 桌面添加图标

    // We post so that the log happens after Application.onCreate()
    mainHandler.post {
      // https://github.com/square/leakcanary/issues/1981
      // We post to a background handler because HeapDumpControl.iCanHasHeap() checks a shared pref
      // which blocks until loaded and that creates a StrictMode violation.
      backgroundHandler.post {
        SharkLog.d {
          when (val iCanHasHeap = HeapDumpControl.iCanHasHeap()) {
            is Yup -> application.getString(R.string.leak_canary_heap_dump_enabled_text)
            is Nope -> application.getString(
              R.string.leak_canary_heap_dump_disabled_text, iCanHasHeap.reason()
            )
          }
        }
      }
    }
  }

  @Synchronized private fun moveToRetained(key: String) {
    removeWeaklyReachableObjects()
    val retainedRef = watchedObjects[key] //通过唯一的UUID取出观察对象
    if (retainedRef != null) {
      retainedRef.retainedUptimeMillis = clock.uptimeMillis() //这个是关联对象被认为保留的时间
      // 责任链模式
      onObjectRetainedListeners.forEach { it.onObjectRetained() }
    }
  }

  override fun onObjectRetained() = scheduleRetainedObjectCheck()

  fun scheduleRetainedObjectCheck() {
    if (this::heapDumpTrigger.isInitialized) {
      heapDumpTrigger.scheduleRetainedObjectCheck()
    }
  }

  fun scheduleRetainedObjectCheck(
    delayMillis: Long = 0L
  ) {
    val checkCurrentlyScheduledAt = checkScheduledAt
    if (checkCurrentlyScheduledAt > 0) { // 通过记录时间戳来避免重复检测
      return
    }
    checkScheduledAt = SystemClock.uptimeMillis() + delayMillis //记录时间
    backgroundHandler.postDelayed({
      checkScheduledAt = 0
      checkRetainedObjects() // 检测留存的对象
    }, delayMillis)
  }

  private fun checkRetainedObjects() {
    // 是否能够heap dump
    val iCanHasHeap = HeapDumpControl.iCanHasHeap()

    val config = configProvider()

    if (iCanHasHeap is Nope) {
      if (iCanHasHeap is NotifyingNope) { // 发送一个通知，点击后开始分析
        // Before notifying that we can't dump heap, let's check if we still have retained object.
        var retainedReferenceCount = objectWatcher.retainedObjectCount

        if (retainedReferenceCount > 0) {
          gcTrigger.runGc() // 调用一次GC,确保是否真的泄漏
          retainedReferenceCount = objectWatcher.retainedObjectCount
        }

        val nopeReason = iCanHasHeap.reason()
        // 判断是否达到阈值，前台是>=5个时会触发，后台是>=1个就会触发
        val wouldDump = !checkRetainedCount(
          retainedReferenceCount, config.retainedVisibleThreshold, nopeReason
        )

        if (wouldDump) {
          val uppercaseReason = nopeReason[0].toUpperCase() + nopeReason.substring(1)
          onRetainInstanceListener.onEvent(DumpingDisabled(uppercaseReason))
          showRetainedCountNotification( // 通知
            objectCount = retainedReferenceCount,
            contentText = uppercaseReason
          )
        }
      } else {
        SharkLog.d {
          application.getString(
            R.string.leak_canary_heap_dump_disabled_text, iCanHasHeap.reason()
          )
        }
      }
      return
    }

    // 如果不能进行堆转储，
    var retainedReferenceCount = objectWatcher.retainedObjectCount

    if (retainedReferenceCount > 0) {
      gcTrigger.runGc()
      retainedReferenceCount = objectWatcher.retainedObjectCount
    }

    if (checkRetainedCount(retainedReferenceCount, config.retainedVisibleThreshold)) return

    val now = SystemClock.uptimeMillis()
    val elapsedSinceLastDumpMillis = now - lastHeapDumpUptimeMillis
    if (elapsedSinceLastDumpMillis < WAIT_BETWEEN_HEAP_DUMPS_MILLIS) {
      onRetainInstanceListener.onEvent(DumpHappenedRecently)
      showRetainedCountNotification(
        objectCount = retainedReferenceCount,
        contentText = application.getString(R.string.leak_canary_notification_retained_dump_wait)
      )
      scheduleRetainedObjectCheck(
        delayMillis = WAIT_BETWEEN_HEAP_DUMPS_MILLIS - elapsedSinceLastDumpMillis
      )
      return
    }

    dismissRetainedCountNotification()
    val visibility = if (applicationVisible) "visible" else "not visible"
    // 分析hprof文件
    dumpHeap(
      retainedReferenceCount = retainedReferenceCount,
      retry = true,
      reason = "$retainedReferenceCount retained objects, app is $visibility"
    )
  }

  private fun dumpHeap(
    retainedReferenceCount: Int,
    retry: Boolean,
    reason: String
  ) {
    val directoryProvider =
      InternalLeakCanary.createLeakDirectoryProvider(InternalLeakCanary.application)
    val heapDumpFile = directoryProvider.newHeapDumpFile() // 创建导出的文件夹

    val durationMillis: Long
    if (currentEventUniqueId == null) {
      currentEventUniqueId = UUID.randomUUID().toString()
    }
    try {
      InternalLeakCanary.sendEvent(DumpingHeap(currentEventUniqueId!!))
      if (heapDumpFile == null) {
        throw RuntimeException("Could not create heap dump file")
      }
      saveResourceIdNamesToMemory()
      val heapDumpUptimeMillis = SystemClock.uptimeMillis()
      KeyedWeakReference.heapDumpUptimeMillis = heapDumpUptimeMillis
      durationMillis = measureDurationMillis {
        configProvider().heapDumper.dumpHeap(heapDumpFile) // 主要方法，用系统导出堆转储文件
      }
      if (heapDumpFile.length() == 0L) {
        throw RuntimeException("Dumped heap file is 0 byte length")
      }
      lastDisplayedRetainedObjectCount = 0
      lastHeapDumpUptimeMillis = SystemClock.uptimeMillis()
      objectWatcher.clearObjectsWatchedBefore(heapDumpUptimeMillis)
      currentEventUniqueId = UUID.randomUUID().toString()
      // 导出情况回调，并根据成功与否通知用户
      InternalLeakCanary.sendEvent(HeapDump(currentEventUniqueId!!, heapDumpFile, durationMillis, reason))
    } catch (throwable: Throwable) {
      InternalLeakCanary.sendEvent(HeapDumpFailed(currentEventUniqueId!!, throwable, retry))
      if (retry) {
        scheduleRetainedObjectCheck(
          delayMillis = WAIT_AFTER_DUMP_FAILED_MILLIS
        )
      }
      showRetainedCountNotification(
        objectCount = retainedReferenceCount,
        contentText = application.getString(
          R.string.leak_canary_notification_retained_dump_failed
        )
      )
      return
    }
  }

  fun sendEvent(event: Event) {
    for(listener in LeakCanary.config.eventListeners) {
      listener.onEvent(event)
    }
  }

object RemoteWorkManagerHeapAnalyzer : EventListener {

  private const val REMOTE_SERVICE_CLASS_NAME = "leakcanary.internal.RemoteLeakCanaryWorkerService"

  internal val remoteLeakCanaryServiceInClasspath by lazy {
    try {
      Class.forName(REMOTE_SERVICE_CLASS_NAME)
      true
    } catch (ignored: Throwable) {
      false
    }
  }

  // 这里所传进来的event就是HeadDump
  override fun onEvent(event: Event) {
    if (event is HeapDump) {
      val application = InternalLeakCanary.application
      // 构建了一个workManagerRequest，这个OneTimeWorkRequest表示任务只会执行一次
      val heapAnalysisRequest =
        OneTimeWorkRequest.Builder(RemoteHeapAnalyzerWorker::class.java).apply { // 指定任务执行的工作类
          val dataBuilder = Data.Builder()
            .putString(ARGUMENT_PACKAGE_NAME, application.packageName)
            .putString(ARGUMENT_CLASS_NAME, REMOTE_SERVICE_CLASS_NAME)
          setInputData(event.asWorkerInputData(dataBuilder))
          with(WorkManagerHeapAnalyzer) { // 任务内容在WorkManagerHeapAnalyzer里面
            addExpeditedFlag()
          }
        }.build()
      SharkLog.d { "Enqueuing heap analysis for ${event.file} on WorkManager remote worker" }
      val workManager = WorkManager.getInstance(application) // 用WorkManager创建了一个异步任务
      workManager.enqueue(heapAnalysisRequest) // 将构建好的heapAnalysisReques入队，开始排队执行
    }
  }
}

internal class RemoteHeapAnalyzerWorker(appContext: Context, workerParams: WorkerParameters) :
  RemoteListenableWorker(appContext, workerParams) {

  override fun startRemoteWork(): ListenableFuture<Result> {
    val heapDump = inputData.asEvent<HeapDump>()
    val result = SettableFuture.create<Result>()
    heapAnalyzerThreadHandler.post { // 开启子线程执行分析任务
      val doneEvent = AndroidDebugHeapAnalyzer.runAnalysisBlocking(heapDump, isCanceled = {
        result.isCancelled
      }) { progressEvent ->
        if (!result.isCancelled) {
          InternalLeakCanary.sendEvent(progressEvent) // 将分析的进度发送出去
        }
      }
      if (result.isCancelled) {
        SharkLog.d { "Remote heap analysis for ${heapDump.file} was canceled" }
      } else {
        InternalLeakCanary.sendEvent(doneEvent) //结束任务
        result.set(Result.success())
      }
    }
    return result
  }

  override fun getForegroundInfoAsync(): ListenableFuture<ForegroundInfo> {
    return applicationContext.heapAnalysisForegroundInfoAsync()
  }
}

ExecutorService executorService = Executors.newFixedThreadPool(2); //固定大小线程池
// 提交一个任务(Runnable)并获取执行结果
Future<?> future = executorService.submit(() -> {
    // 任务代码
});

// 提交一个Runnable对象，不返回执行结果
executorService.execute(() -> {
    // 任务代码
});

executorService.shutdown(); // 线程池的关闭
executorService.shutdownNow(); // 尝试停止所有正在执行的任务，并返回未执行的任务列表

<style name="WelcomeTheme" parent="Theme.AppCompat.NoActionBar">
	<!--设置背景颜色或者图片-->
	<item name="android:windowBackground">@drawable/xxxx</item>
	<!--设置没有ActionBar-->
	<item name="android:windowNoTitle">true</item>
	<!--设置顶部状态栏颜色-->
	<item name="android:statusBarColor" >@color/xxxx</item>
</style>

<activity
    android:name=".ui.activity.LoginActivity"
    android:exported="true"
    android:theme="@style/WelcomeTheme">
    <intent-filter>
        <action android:name="android.intent.action.MAIN" />

        <category android:name="android.intent.category.LAUNCHER" />
    </intent-filter>
</activity>

class MainApplication : Application() {
    override fun onCreate() {
        super.onCreate()
        // 主线程仅处理轻量级任务
        initLightweightComponents()
        // 异步初始化耗时组件
        CoroutineScope(Dispatchers.IO).launch {
            initHeavyComponents()
        }
    }

    private fun initLightweightComponents() {
        // 如 SharedPreferences、基础工具类
    }

    private suspend fun initHeavyComponents() {
        // 如网络库、数据库、SDK 初始化
        withContext(Dispatchers.IO) {
            RetrofitClient.init()
            RoomDatabase.init()
            Analytics.init()
        }
    }
}

class MainActivity : AppCompatActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)
        findViewById<Button>(R.id.btn_lick).setOnClickListener {
            Thread.sleep(30000)
        }
    }
}

ContextImpl.startService()->ContextImpl.startServiceCommon()->ActivityManagerService.startService()
->ActiveServices.startServiceLocked()->ActiveServices.startServiceInnerLocked()->ActiveServices.bringUpServiceLocked()
->ActiveServices.realStartServiceLocked()

//com.android.server.am.ActiveServices.java
private final void realStartServiceLocked(ServiceRecord r,
        ProcessRecord app, boolean execInFg) throws RemoteException {
    ......
    bumpServiceExecutingLocked(r, execInFg, "create");

    ......
    try {
        //IPC通知app进程启动Service
        app.thread.scheduleCreateService(r, r.serviceInfo,
                mAm.compatibilityInfoForPackage(r.serviceInfo.applicationInfo),
                app.getReportedProcState());
    } catch (DeadObjectException e) {
    } finally {
    }
}

private final void bumpServiceExecutingLocked(ServiceRecord r, boolean fg, String why) {
    scheduleServiceTimeoutLocked(r.app);
    .....
}

final ActivityManagerService mAm;

// How long we wait for a service to finish executing.
static final int SERVICE_TIMEOUT = 20*1000;

// How long we wait for a service to finish executing.
static final int SERVICE_BACKGROUND_TIMEOUT = SERVICE_TIMEOUT * 10;

void scheduleServiceTimeoutLocked(ProcessRecord proc) {
    //mAm是AMS，mHandler是AMS里面的一个Handler
    Message msg = mAm.mHandler.obtainMessage(
            ActivityManagerService.SERVICE_TIMEOUT_MSG);
    msg.obj = proc;
    //发个延迟消息给AMS里面的一个Handler,相当于在这里埋了一个炸弹
    mAm.mHandler.sendMessageDelayed(msg,
            proc.execServicesFg ? SERVICE_TIMEOUT : SERVICE_BACKGROUND_TIMEOUT); // 这里就是设置是前台还是后台服务时间
}

//android.app.ActivityThread.java
@UnsupportedAppUsage
private void handleCreateService(CreateServiceData data) {
    ......
    Service service = null;
    try {
        //1. 初始化Service
        ContextImpl context = ContextImpl.createAppContext(this, packageInfo);
        Application app = packageInfo.makeApplication(false, mInstrumentation);
        java.lang.ClassLoader cl = packageInfo.getClassLoader();
        service = packageInfo.getAppFactory()
                .instantiateService(cl, data.info.name, data.intent);
        ......
        service.attach(context, this, data.info.name, data.token, app,
                ActivityManager.getService());
        //2. Service执行onCreate，启动完成
        service.onCreate();
        mServices.put(data.token, service);
        try {
            //3. Service启动完成，需要通知AMS
            ActivityManager.getService().serviceDoneExecuting(
                    data.token, SERVICE_DONE_EXECUTING_ANON, 0, 0);
        } catch (RemoteException e) {
        }
    } catch (Exception e) {
    }
}

private void serviceDoneExecutingLocked(ServiceRecord r, boolean inDestroying,
        boolean finishing) {
    ......
    mAm.mHandler.removeMessages(ActivityManagerService.SERVICE_TIMEOUT_MSG, r.app);
    ......
}

//com.android.server.am.ActivityManagerService.java

final MainHandler mHandler;

final class MainHandler extends Handler {
    @Override
    public void handleMessage(Message msg) {
        switch (msg.what) {
        	......
        	case SERVICE_TIMEOUT_MSG: {
            	//这个mServices是ActiveServices
            	mServices.serviceTimeout((ProcessRecord)msg.obj);
        	} break;
        }
        ......
    }
    ......
}

//com.android.server.am.ActiveServices.java
void serviceTimeout(ProcessRecord proc) {
    String anrMessage = null;
    synchronized(mAm) {
        //计算是否有service超时
        final long now = SystemClock.uptimeMillis();
        final long maxTime =  now -
                (proc.execServicesFg ? SERVICE_TIMEOUT : SERVICE_BACKGROUND_TIMEOUT);
        ServiceRecord timeout = null;
        for (int i=proc.executingServices.size()-1; i>=0; i--) {
            ServiceRecord sr = proc.executingServices.valueAt(i);
            if (sr.executingStart < maxTime) {
                timeout = sr;
                break;
            }
        }
        if (timeout != null && mAm.mProcessList.mLruProcesses.contains(proc)) {
            anrMessage = "executing service " + timeout.shortInstanceName;
        }
    }

    if (anrMessage != null) {
        //有超时的Service,mAm是AMS，mAnrHelper是AnrHelper
        mAm.mAnrHelper.appNotResponding(proc, anrMessage);
    }
}

void appNotResponding(ProcessRecord anrProcess, String activityShortComponentName,
        ApplicationInfo aInfo, String parentShortComponentName,
        WindowProcessController parentProcess, boolean aboveSystem, String annotation) {
    //添加AnrRecord到List里面
    synchronized (mAnrRecords) {
        mAnrRecords.add(new AnrRecord(anrProcess, activityShortComponentName, aInfo,
                parentShortComponentName, parentProcess, aboveSystem, annotation));
    }
    startAnrConsumerIfNeeded();
}
private void startAnrConsumerIfNeeded() {
    if (mRunning.compareAndSet(false, true)) {
        //开个子线程来处理
        new AnrConsumerThread().start();
    }
}

private class AnrConsumerThread extends Thread {
    @Override
    public void run() {
        AnrRecord r;
        while ((r = next()) != null) {
            ......
            //这里的r就是AnrRecord
            r.appNotResponding(onlyDumpSelf);
            ......
        }
    }
}
private static class AnrRecord {
    void appNotResponding(boolean onlyDumpSelf) {
        //mApp是ProcessRecord
        mApp.appNotResponding(mActivityShortComponentName, mAppInfo,
                mParentShortComponentName, mParentProcess, mAboveSystem, mAnnotation,
                onlyDumpSelf);
    }
}

//com.android.server.am.ProcessRecord.java
void appNotResponding(String activityShortComponentName, ApplicationInfo aInfo,
        String parentShortComponentName, WindowProcessController parentProcess,
        boolean aboveSystem, String annotation, boolean onlyDumpSelf) {
    ArrayList<Integer> firstPids = new ArrayList<>(5);
    SparseArray<Boolean> lastPids = new SparseArray<>(20);

    mWindowProcessController.appEarlyNotResponding(annotation, () -> kill("anr",
                ApplicationExitInfo.REASON_ANR, true));

    long anrTime = SystemClock.uptimeMillis();
    if (isMonitorCpuUsage()) {
        mService.updateCpuStatsNow();
    }

    final boolean isSilentAnr;
    synchronized (mService) {
		//一些特殊的情况
        // PowerManager.reboot() can block for a long time, so ignore ANRs while shutting down.
		//正在重启
        if (mService.mAtmInternal.isShuttingDown()) {
            Slog.i(TAG, "During shutdown skipping ANR: " + this + " " + annotation);
            return;
        } else if (isNotResponding()) {
			//已经处于ANR流程中
            Slog.i(TAG, "Skipping duplicate ANR: " + this + " " + annotation);
            return;
        } else if (isCrashing()) {
			//正在crash的状态
            Slog.i(TAG, "Crashing app skipping ANR: " + this + " " + annotation);
            return;
        } else if (killedByAm) {
			//app已经被killed
            Slog.i(TAG, "App already killed by AM skipping ANR: " + this + " " + annotation);
            return;
        } else if (killed) {
			//app已经死亡了
            Slog.i(TAG, "Skipping died app ANR: " + this + " " + annotation);
            return;
        }

        // In case we come through here for the same app before completing
        // this one, mark as anring now so we will bail out.
		//做个标记
        setNotResponding(true);

        // Log the ANR to the event log.
        EventLog.writeEvent(EventLogTags.AM_ANR, userId, pid, processName, info.flags,
                annotation);

        // Dump thread traces as quickly as we can, starting with "interesting" processes.
        firstPids.add(pid);

        // Don't dump other PIDs if it's a background ANR or is requested to only dump self.
		//沉默的anr : 这里表示后台anr
        isSilentAnr = isSilentAnr();
        if (!isSilentAnr && !onlyDumpSelf) {
            int parentPid = pid;
            if (parentProcess != null && parentProcess.getPid() > 0) {
                parentPid = parentProcess.getPid();
            }
            if (parentPid != pid) firstPids.add(parentPid);

            if (MY_PID != pid && MY_PID != parentPid) firstPids.add(MY_PID);

			//遍历LRU进程的List，选择需要dump的进程
            for (int i = getLruProcessList().size() - 1; i >= 0; i--) {
                ProcessRecord r = getLruProcessList().get(i);
                if (r != null && r.thread != null) {
                    int myPid = r.pid;
                    if (myPid > 0 && myPid != pid && myPid != parentPid && myPid != MY_PID) {
                        // 如果是Persistent的进程，添加进去
                        if (r.isPersistent()) {
                            firstPids.add(myPid);
                            if (DEBUG_ANR) Slog.i(TAG, "Adding persistent proc: " + r);
                        } else if (r.treatLikeActivity) {
                            // 如果带有BIND_TREAT_LIKE_ACTVITY标签的进程，添加进去
                            firstPids.add(myPid);
                            if (DEBUG_ANR) Slog.i(TAG, "Adding likely IME: " + r);
                        } else {
                            // 将其他进程添加到lastPids中
                            lastPids.put(myPid, Boolean.TRUE);
                            if (DEBUG_ANR) Slog.i(TAG, "Adding ANR proc: " + r);
                        }
                    }
                }
            }
        }
    }

    ......

    int[] pids = nativeProcs == null ? null : Process.getPidsForCommands(nativeProcs);
    ArrayList<Integer> nativePids = null;

    if (pids != null) {
        nativePids = new ArrayList<>(pids.length);
        for (int i : pids) {
            nativePids.add(i);
        }
    }

    // For background ANRs, don't pass the ProcessCpuTracker to
    // avoid spending 1/2 second collecting stats to rank lastPids.
    StringWriter tracesFileException = new StringWriter();
    // To hold the start and end offset to the ANR trace file respectively.
    final long[] offsets = new long[2];

    // 按照顺序dump进程的堆栈
    File tracesFile = ActivityManagerService.dumpStackTraces(firstPids,
            isSilentAnr ? null : processCpuTracker, isSilentAnr ? null : lastPids,
            nativePids, tracesFileException, offsets);
		......
}

public static Pair<Long, Long> dumpStackTraces(String tracesFile, ArrayList<Integer> firstPids,
        ArrayList<Integer> nativePids, ArrayList<Integer> extraPids) {

    // 最多dump 20秒
    long remainingTime = 20 * 1000;

    // First collect all of the stacks of the most important pids.
    if (firstPids != null) {
        int num = firstPids.size();
        for (int i = 0; i < num; i++) {
            final int pid = firstPids.get(i);
            final long timeTaken = dumpJavaTracesTombstoned(pid, tracesFile, remainingTime);
            remainingTime -= timeTaken;
            if (remainingTime <= 0) {
                Slog.e(TAG, "Aborting stack trace dump (current firstPid=" + pid
                        + "); deadline exceeded.");
                return firstPidStart >= 0 ? new Pair<>(firstPidStart, firstPidEnd) : null;
            }
        }
    }
    ......
}

bool debuggerd_trigger_dump(pid_t tid, DebuggerdDumpType dump_type, unsigned int timeout_ms, unique_fd output_fd) {
    //pid是从AMS那边传过来的，即需要dump堆栈的进程
		pid_t pid = tid;
    //......

    // Send the signal.
		//从android_os_Debug_dumpJavaBacktraceToFileTimeout过来的，dump_type为kDebuggerdJavaBacktrace
    const int signal = (dump_type == kDebuggerdJavaBacktrace) ? SIGQUIT : BIONIC_SIGNAL_DEBUGGER;
    sigval val = {.sival_int = (dump_type == kDebuggerdNativeBacktrace) ? 1 : 0};
		//sigqueue：在队列中向指定进程发送一个信号和数据，成功返回0
    if (sigqueue(pid, signal, val) != 0) {
      log_error(output_fd, errno, "failed to send signal to pid %d", pid); // 发送失败
      return false;
    }
    //......
    LOG(INFO) << TAG "done dumping process " << pid;
    return true;
}

implementation("com.github.anrwatchdog:anrwatchdog:1.4.0")

val anrWatchDog = ANRWatchDog()
anrWatchDog.start();

anrWatchDog.setANRListener {
    Log.e("ANR-WatchDog", "ANR detected!", it);
}

    private final Handler _uiHandler = new Handler(Looper.getMainLooper());
    private final int _timeoutInterval;

    private String _namePrefix = "";
    private boolean _logThreadsWithoutStackTrace = false;
    private boolean _ignoreDebugger = false;

    private volatile long _tick = 0;
    private volatile boolean _reported = false;

    private final Runnable _ticker = new Runnable() {
        @Override public void run() {
            _tick = 0;
            _reported = false;
        }
    };

    @SuppressWarnings("NonAtomicOperationOnVolatileField")
    @Override
    public void run() {
        setName("|ANR-WatchDog|");

        // 设定的超时时长，可以自己修改
        long interval = _timeoutInterval;
        while (!isInterrupted()) {
            // _tick为标志，如果主线程执行了发送的这个消息，那么_tick就会被赋值为0
            boolean needPost = _tick == 0;
            // 把_tick加上一个超时的时长，主线程执行了才知道
            _tick += interval;
            if (needPost) {
                // 向主线程发送_ticker消息
                _uiHandler.post(_ticker);
            }

            // 让子线程休眠interval的时间，如果这之后_tick != 0,说明卡顿了，没来得及执行消息
            try {
                Thread.sleep(interval);
            } catch (InterruptedException e) {
                _interruptionListener.onInterrupted(e);
                return ;
            }

            // 如果_tick不为0且没有被debug
            if (_tick != 0 && !_reported) {
                // 排除debug的情况
                if (!_ignoreDebugger && (Debug.isDebuggerConnected() || Debug.waitingForDebugger())) {
                    Log.w("ANRWatchdog", "An ANR was detected but ignored because the debugger is connected (you can prevent this with setIgnoreDebugger(true))");
                    _reported = true;
                    continue ;
                }

                // 自定义一个Interceptor告诉WatchDog,当前上下文环境是否可以上报
                interval = _anrInterceptor.intercept(_tick);
                if (interval > 0) {
                    continue;
                }

                // 上报线程堆栈
                final ANRError error;
                if (_namePrefix != null) {
                    error = ANRError.New(_tick, _namePrefix, _logThreadsWithoutStackTrace);
                } else {
                    error = ANRError.NewMainOnly(_tick);
                }
                // 进行回调
                _anrListener.onAppNotResponding(error);
                interval = _timeoutInterval;
                _reported = true;
            }
        }
    }

----- pid 1865 at 2025-07-02 16:21:19.818055120+0800 -----
Cmd line: com.chaoxing.mobile
Build fingerprint: 'vivo/V2218A/V2218A:12/V417IR/913:user/release-keys'
ABI: 'x86_64'
Build type: optimized
Zygote loaded classes=20024 post zygote classes=8711
Dumping registered class loaders
#0 dalvik.system.PathClassLoader: [], parent #1
#1 java.lang.BootClassLoader: [], no parent
#2 dalvik.system.PathClassLoader: [...], parent #1
#3 dalvik.system.PathClassLoader: [/system/product/app/webview/webview.apk], parent #1
Done dumping class loaders
Classes initialized: 0 in 0
Intern table: 37019 strong; 957 weak
JNI: CheckJNI is off; globals=496 (plus 68 weak)
Libraries: ... (23)

// 已分配堆内存32MB，其中29MB已用，有218118个对象
Heap: 6% free, 29MB/32MB; 218118 objects
Total number of allocations 2207826 // 进程创建到现在一共有多少对象
Total bytes allocated 182MB // 进程创建到现在一共申请了多少内存
Total bytes freed 152MB // 进程创建到现在一共释放了多少内存
Free memory 2165KB // 不扩展堆的情况下可用的内存
Free memory until GC 2165KB // GC前的可用内存
Free memory until OOME 482MB // OOM之前的可用内存，如果这个值很小，那么可能说明app内存紧张
Total memory 32MB // 总内存，这里表示目前只申请了这么多内存
Max memory 512MB // 进程最多能申请的内存

... // 省略GC相关的信息

// 当前共91个线程
DALVIK THREADS (91):

// Signal Catcher线程调用栈
"Signal Catcher" daemon prio=10 tid=5 Runnable
  | group="system" sCount=0 ucsCount=0 flags=0 obj=0x12c00390 self=0x7b560d1b32c0
  | sysTid=1872 nice=-20 cgrp=default sched=0/0 handle=0x7b5488fcacf0
  | state=R schedstat=( 1338863 0 4 ) utm=0 stm=0 core=0 HZ=100
  | stack=0x7b5488ed4000-0x7b5488ed6000 stackSize=987KB
  | held mutexes= "mutator lock"(shared held)
  native: #00 pc 000000000073dbef  ...
  native: #01 pc 0000000000883850  ...
  native: #02 pc 00000000008a45da  ...
  native: #04 pc 000000000089c6fb  ...
  native: #05 pc 000000000089bf0f  ...
  native: #06 pc 00000000008371f8  ...
  native: #07 pc 000000000084d324  ...
  native: #08 pc 000000000084c095  ...
  native: #09 pc 00000000000cc9fa  ...
  native: #10 pc 00000000000639b7  ...

"main" prio=5 tid=1 Native
  | group="main" sCount=1 ucsCount=0 flags=1 obj=0x728641c8 self=0x7b560d1ac380
  | sysTid=1865 nice=0 cgrp=default sched=0/0 handle=0x7b575403f520
  | state=S schedstat=( 2714047895 1267425784 2361 ) utm=155 stm=115 core=2 HZ=100
  | stack=0x7ffce5ace000-0x7ffce5ad0000 stackSize=8188KB
  | held mutexes=
  native: #00 pc 00000000000b78aa  ...
  native: #01 pc 000000000001a00a  ...
  native: #02 pc 0000000000019eae  ...
  native: #03 pc 000000000016ab13  ...

// Signal Catcher线程调用栈
"Signal Catcher" daemon prio=10 tid=5 Runnable
  | group="system" sCount=0 ucsCount=0 flags=0 obj=0x12c00390 self=0x7b560d1b32c0
  | sysTid=1872 nice=-20 cgrp=default sched=0/0 handle=0x7b5488fcacf0
  | state=R schedstat=( 1338863 0 4 ) utm=0 stm=0 core=0 HZ=100
  | stack=0x7b5488ed4000-0x7b5488ed6000 stackSize=987KB
  | held mutexes= "mutator lock"(shared held)

"main" prio=5 tid=1 Native
  | group="main" sCount=1 dsCount=0 flags=1 obj=0x74b38080 self=0x7ad9014c00
  | sysTid=23081 nice=0 cgrp=default sched=0/0 handle=0x7b5fdc5548
  | state=S schedstat=( 284838633 166738594 505 ) utm=21 stm=7 core=1 HZ=100
  | stack=0x7fc95da000-0x7fc95dc000 stackSize=8MB
  | held mutexes=
  kernel: __switch_to+0xb0/0xbc
  kernel: SyS_epoll_wait+0x288/0x364
  kernel: SyS_epoll_pwait+0xb0/0x124
  kernel: cpu_switch_to+0x38c/0x2258
  native: #00 pc 000000000007cd8c  /system/lib64/libc.so (__epoll_pwait+8)
  native: #01 pc 0000000000014d48  /system/lib64/libutils.so (android::Looper::pollInner(int)+148)
  native: #02 pc 0000000000014c18  /system/lib64/libutils.so (android::Looper::pollOnce(int, int*, int*, void**)+60)
  native: #03 pc 00000000001275f4  /system/lib64/libandroid_runtime.so (android::android_os_MessageQueue_nativePollOnce(_JNIEnv*, _jobject*, long, int)+44)
  at android.os.MessageQueue.nativePollOnce(Native method)
  at android.os.MessageQueue.next(MessageQueue.java:330)
  at android.os.Looper.loop(Looper.java:169)
  at android.app.ActivityThread.main(ActivityThread.java:7073)
  at java.lang.reflect.Method.invoke(Native method)
  at com.android.internal.os.RuntimeInit$MethodAndArgsCaller.run(RuntimeInit.java:536)
  at com.android.internal.os.ZygoteInit.main(ZygoteInit.java:876)

CPU usage from 0ms to 10625ms later (2020-03-09 14:38:31.633 to 2020-03-09 14:38:42.257):
  543% 2045/com.test.demo: 54% user + 89% kernel / faults: 4608 minor 1 major //注意看这里
  99% 674/android.hardware.camera.provider@2.4-service: 81% user + 18% kernel / faults: 403 minor
  24% 32589/com.wang.test: 22% user + 1.4% kernel / faults: 7432 minor 1 major
  ......

adb shell perfetto -o /data/misc/perfetto-traces/trace_file.perfetto-trace -t 20s \ sched freq idle am wm gfx view binder_driver hal dalvik camera input res memory

adb pull /data/misc/perfetto-traces/trace_file.perfetto-trace

# 可能需要梯子
curl -O https://raw.githubusercontent.com/google/perfetto/master/tools/record_android_trace chmod u+x record_android_trace ./record_android_trace -o trace_file.perfetto-trace -t 10s -b 64mb \ sched freq idle am wm gfx view binder_driver hal dalvik camera input res memory

class ExampleAdapter(private val items: List<MyItem>) : RecyclerView.Adapter<ExampleAdapter.ExampleViewHolder>() {

    class ExampleViewHolder(view: View) : RecyclerView.ViewHolder(view) {
        val titleView: TextView = view.findViewById(R.id.title)
        val contentView: TextView = view.findViewById(R.id.content)
    }


    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): ExampleViewHolder {
        val view = LayoutInflater.from(parent.context).inflate(R.layout.item_layout,parent,false)
        return ExampleViewHolder(view)
    }

    // 全量绑定的方法，用于初次绑定视图或者payload为空时
    override fun onBindViewHolder(holder: ExampleViewHolder, position: Int) {
        val item = items[position]
        holder.titleView.text = item.title
        holder.contentView.text = item.content
    }

    // 重写带payload参数的onBindViewHolder
    override fun onBindViewHolder(
        holder: ExampleViewHolder,
        position: Int,
        payloads: MutableList<Any>
    ) {
        if(payloads.isEmpty()) {
            // payloads为空，进行全量绑定
            super.onBindViewHolder(holder, position, payloads)
        } else {
            // 取出payload
            val bundle = payloads[0] as Bundle
            // 用if判断更新的类型进行更新
            if(bundle.containsKey("title")) {
                holder.titleView.text = bundle.getString("title")
            }
            if(bundle.containsKey("content")) {
                holder.contentView.text = bundle.getString("content")
            }
        }
    }

    // 暴露给外部的局部刷新方法
    fun updateTitle(position: Int, newTitle: String) {
        items[position].title = newTitle
        val payload = Bundle()
        payload.putString("title",newTitle)
        // 调用局部刷新的方法
        notifyItemChanged(position,payload)
    }

    fun updateContent(position: Int, newContent: String) {
        items[position].content = newContent
        val payload = Bundle()
        payload.putString("content", newContent)
        notifyItemChanged(position, payload)
    }

    override fun getItemCount() = items.size
}

public final void notifyItemChanged(int position, @Nullable Object payload) {
    mObservable.notifyItemRangeChanged(position, 1, payload);
}

public void notifyItemRangeChanged(int positionStart, int itemCount,
        @Nullable Object payload) {
    // since onItemRangeChanged() is implemented by the app, it could do anything, including
    // removing itself from {@link mObservers} - and that could cause problems if
    // an iterator is used on the ArrayList {@link mObservers}.
    // to avoid such problems, just march thru the list in the reverse order.
    // 遍历集合取出对象
    for (int i = mObservers.size() - 1; i >= 0; i--) {
        mObservers.get(i).onItemRangeChanged(positionStart, itemCount, payload);
    }
}

private class RecyclerViewDataObserver extends AdapterDataObserver {
	...
    @Override
    public void onItemRangeChanged(int positionStart, int itemCount, Object payload) {
        assertNotInLayoutOrScroll(null);
        if (mAdapterHelper.onItemRangeChanged(positionStart, itemCount, payload)) {
            triggerUpdateProcessor();
        }
    }
    ...
}

void triggerUpdateProcessor() {
    if (POST_UPDATES_ON_ANIMATION && mHasFixedSize && mIsAttached) {
        ViewCompat.postOnAnimation(RecyclerView.this, mUpdateChildViewsRunnable);
    } else {
        mAdapterUpdateDuringMeasure = true;
        requestLayout();
    }
}

boolean onItemRangeChanged(int positionStart, int itemCount, Object payload) {
    if (itemCount < 1) {
        return false;
    }
    mPendingUpdates.add(obtainUpdateOp(UpdateOp.UPDATE, positionStart, itemCount, payload)); // 将payload包装成对象放入集合中
    mExistingUpdateTypes |= UpdateOp.UPDATE;
    return mPendingUpdates.size() == 1; // size == 1才返回true
}

mCallback.markViewHoldersUpdated(op.positionStart, op.itemCount, op.payload);

@Override
public void markViewHoldersUpdated(int positionStart, int itemCount, Object payload) {
    viewRangeUpdate(positionStart, itemCount, payload);
    mItemsChanged = true;
}

    void viewRangeUpdate(int positionStart, int itemCount, Object payload) {
        final int childCount = mChildHelper.getUnfilteredChildCount();
        final int positionEnd = positionStart + itemCount;

        for (int i = 0; i < childCount; i++) {
            final View child = mChildHelper.getUnfilteredChildAt(i);
            final ViewHolder holder = getChildViewHolderInt(child);
            if (holder == null || holder.shouldIgnore()) {
                continue;
            }
            if (holder.mPosition >= positionStart && holder.mPosition < positionEnd) {
                // We re-bind these view holders after pre-processing is complete so that
                // ViewHolders have their final positions assigned.
                holder.addFlags(ViewHolder.FLAG_UPDATE);
                holder.addChangePayload(payload); //在这个函数里面把payload传了进去
                // lp cannot be null since we get ViewHolder from it.
                ((LayoutParams) child.getLayoutParams()).mInsetsDirty = true;
            }
        }
        mRecycler.viewRangeUpdate(positionStart, itemCount);
    }

void addChangePayload(Object payload) {
    if (payload == null) {
        addFlags(FLAG_ADAPTER_FULLUPDATE);
    } else if ((mFlags & FLAG_ADAPTER_FULLUPDATE) == 0) {
        createPayloadsIfNeeded(); // 创建新的payloads集合
        mPayloads.add(payload); // 把当前的payload添加进集合里
    }
}

private void createPayloadsIfNeeded() {
    if (mPayloads == null) {
        mPayloads = new ArrayList<Object>();
        mUnmodifiedPayloads = Collections.unmodifiableList(mPayloads);
    }
}

List<Object> getUnmodifiedPayloads() {
    if ((mFlags & FLAG_ADAPTER_FULLUPDATE) == 0) {
        if (mPayloads == null || mPayloads.size() == 0) {
            // Initial state,  no update being called.
            return FULLUPDATE_PAYLOADS;
        }
        // there are none-null payloads
        return mUnmodifiedPayloads;
    } else {
        // a full update has been called.
        return FULLUPDATE_PAYLOADS;
    }
}

boolean canReuseUpdatedViewHolder(ViewHolder viewHolder) {
    return mItemAnimator == null || mItemAnimator.canReuseUpdatedViewHolder(viewHolder,
            viewHolder.getUnmodifiedPayloads());
}

    @Override
    public boolean canReuseUpdatedViewHolder(@NonNull RecyclerView.ViewHolder viewHolder,
            @NonNull List<Object> payloads) {
        return !payloads.isEmpty() || super.canReuseUpdatedViewHolder(viewHolder, payloads);
    }

        void scrapView(View view) {
            final ViewHolder holder = getChildViewHolderInt(view);
            if (holder.hasAnyOfTheFlags(ViewHolder.FLAG_REMOVED | ViewHolder.FLAG_INVALID)
                    || !holder.isUpdated() || canReuseUpdatedViewHolder(holder)) {
                if (holder.isInvalid() && !holder.isRemoved() && !mAdapter.hasStableIds()) {
                    throw new IllegalArgumentException("Called scrap view with an invalid view."
                            + " Invalid views cannot be reused from scrap, they should rebound from"
                            + " recycler pool." + exceptionLabel());
                }
                holder.setScrapContainer(this, false);
                mAttachedScrap.add(holder);
            } else {
                if (mChangedScrap == null) {
                    mChangedScrap = new ArrayList<ViewHolder>();
                }
                holder.setScrapContainer(this, true);
                mChangedScrap.add(holder);
            }
        }
